Research: Aging Gene Communities

The experiment

I wanted to try seeing if there was a central mechanism for aging where all the aging genes are clustered together and talk with each other due to the closely connected network discovered in the previous aging research.

The data

The network is downloaded from https://downloads.thebiogrid.org/File/BioGRID/Release-Archive/BIOGRID-5.0.255/BIOGRID-ORGANISM-5.0.255.tab3.zip it uses the mus musculus file for lab mice. Note there are genes in biogrid that aren’t found in gene_info like 6622 is only found for humans.

The way I converted between Entrez ids and actual gene names I used https://www.ncbi.nlm.nih.gov/books/NBK3840/?utm_source=chatgpt.com#:~:text=You%20can%20therefore%20convert%20any%20GeneID%20into%20its%20current%20names%20by%20using%20the%20definitions%20provided%20in%20the%20file%20available%20as%20https%3A//ftp.ncbi.nlm.nih.gov/gene/DATA/gene_info.gz Note there are symbols collisions, the synonyms for a gene can be the same for multiple genes.

The code

The code can be found here: https://github.com/luojxxx/Aging-community

Basically I took the gene regulatory network and ran the Louvain algorithm on it at increasing resolution to separate it into communities, so that I had a everything from all genes are in one community to each gene is in it’s own community. Then to decide which resolution (and splitting up of the genes into communities) is the optimal one: Each gene community is scored based on it’s average score formed from the aging gene relatedness metric from the previous research divided by the number of genes in that community. Then I take the average scores from each community and determine the standard deviation for that particular split. The rationale being a high standard deviation would have some communities with very high scores and some with very low ones, thus separating the aging genes from the rest. Furthermore the standard deviation is divided by the number of communities to penalize the score for having too many communities.

The results

The scoring of the different ways to partition the genes is below:

0 numCommunities: 68 maxScore: 0.0007488837258844799 networkAverageScore: 1.101299596888941 1 numCommunities: 98 maxScore: 0.003251776545849143 networkAverageScore: 3.3181393324991255 2 numCommunities: 125 maxScore: 0.005494769466338331 networkAverageScore: 4.3958155730706645 3 numCommunities: 161 maxScore: 0.0069487645459496965 networkAverageScore: 4.316002823571241 4 numCommunities: 191 maxScore: 0.007090620598480407 networkAverageScore: 3.712366805487124 5 numCommunities: 224 maxScore: 0.007798266424623854 networkAverageScore: 3.4813689395642204 6 numCommunities: 254 maxScore: 0.009964267658910406 networkAverageScore: 3.9229400231930733 7 numCommunities: 282 maxScore: 0.009442697259654121 networkAverageScore: 3.3484742055511068 8 numCommunities: 306 maxScore: 0.009427016843352834 networkAverageScore: 3.0807244586120373 9 numCommunities: 327 maxScore: 0.010570204795706452 networkAverageScore: 3.23247853079708 10 numCommunities: 344 maxScore: 0.011201984148051368 networkAverageScore: 3.256390740712607 11 numCommunities: 359 maxScore: 0.010791212996202157 networkAverageScore: 3.00590891259113 12 numCommunities: 383 maxScore: 0.01044831150033106 networkAverageScore: 2.7280186684937493 13 numCommunities: 412 maxScore: 0.011006539459555174 networkAverageScore: 2.6714901600862073 14 numCommunities: 429 maxScore: 0.010987803969362013 networkAverageScore: 2.561259666517952 15 numCommunities: 445 maxScore: 0.011530432522332485 networkAverageScore: 2.591108431984828 16 numCommunities: 469 maxScore: 0.012601752020094066 networkAverageScore: 2.6869407292311442 17 numCommunities: 485 maxScore: 0.013875016189636956 networkAverageScore: 2.860828080337517 18 numCommunities: 494 maxScore: 0.014028125071537946 networkAverageScore: 2.8397014314854143 19 numCommunities: 514 maxScore: 0.014232930192399346 networkAverageScore: 2.769052566614659 20 numCommunities: 542 maxScore: 0.013790700370515576 networkAverageScore: 2.5444096624567485 21 numCommunities: 561 maxScore: 0.012914291733680236 networkAverageScore: 2.3020127867522704 22 numCommunities: 579 maxScore: 0.014295785289177639 networkAverageScore: 2.4690475456265353 23 numCommunities: 607 maxScore: 0.014441565642706062 networkAverageScore: 2.3791706165907844 24 numCommunities: 622 maxScore: 0.014512585372182692 networkAverageScore: 2.3332130823444843 25 numCommunities: 637 maxScore: 0.014803833405518186 networkAverageScore: 2.3239926853246757 26 numCommunities: 667 maxScore: 0.015379564261291636 networkAverageScore: 2.305781748319586 27 numCommunities: 681 maxScore: 0.015302882251262605 networkAverageScore: 2.2471192733131575 28 numCommunities: 689 maxScore: 0.015003367209687308 networkAverageScore: 2.1775569244829183 29 numCommunities: 696 maxScore: 0.015411276232991931 networkAverageScore: 2.2142638265793004

As you can see the highest scoring partition is the 2nd one with 125 communities. This is a very coarse grained resolution, but it could still be useful because if all the aging related genes are in one cluster it still tells us something. Also if there aren’t that many genes in the top community, it still works. So the next step is to see the average scores of each community, which is below (the number on the left is the community ID number and the right is the score):

{32: 0.02683359144917233, 25: 0.02344140892791225, 37: 0.01888267530849549, 12: 0.018163231353081892, 17: 0.016936248385012925, 13: 0.015910983376810794, 36: 0.015590394504566734, 15: 0.014450073770012853, 49: 0.01438738925802879, 26: 0.014037323082948439, 29: 0.0136811927732839, 47: 0.012961355190601771, 35: 0.012087931342665763, 2: 0.010733670637428385, 38: 0.010633674787744553, 50: 0.010525420714355803, 21: 0.009787355701154386, 10: 0.009431895044839642, 31: 0.008848716614197215, 14: 0.008797374824475353, 22: 0.006798205821359797, 11: 0.006606083307721204, 52: 0.0061752566520008375, 3: 0.006132287608704209, 39: 0.005012731787350247, 30: 0.00480471680420105, 19: 0.0039896489421834625, 6: 0.003815734359907868, 55: 0.003772044573643411, 28: 0.00376632699841627, 24: 0.003611700978523318, 27: 0.003400198989479512, 44: 0.0030413023255813957, 16: 0.003037537438336856, 54: 0.0026286384708922327, 9: 0.0026116613774978923, 53: 0.0025319229112833763, 41: 0.0020119866560151483, 1: 0.001977977809047519, 23: 0.0016649709302325576, 7: 0.0015174168482369158, 43: 0.0014001098699871815, 0: 0.001192218155660601, 4: 0.0010802861243342124, 20: 0.0009344958683602298, 34: 0.0007821404552051255, 33: 0.0007460642986088988, 40: 0.0007303217335130884, 45: 0.00044825494098749916, 46: 0.0003260562015503876, 42: 0.00021987110149630432, 18: 0.00021666390528979397, 5: 0.00017405412808369267, 51: 7.711668176784456e-05, 80: 0.0, 99: 0.0, 114: 0.0, 122: 0.0, 78: 0.0, 70: 0.0, 108: 0.0, 107: 0.0, 72: 0.0, 66: 0.0, 109: 0.0, 110: 0.0, 75: 0.0, 111: 0.0, 112: 0.0, 113: 0.0, 115: 0.0, 82: 0.0, 92: 0.0, 123: 0.0, 116: 0.0, 117: 0.0, 118: 0.0, 119: 0.0, 87: 0.0, 65: 0.0, 77: 0.0, 68: 0.0, 120: 0.0, 121: 0.0, 106: 0.0, 105: 0.0, 76: 0.0, 101: 0.0, 94: 0.0, 90: 0.0, 61: 0.0, 81: 0.0, 98: 0.0, 97: 0.0, 104: 0.0, 103: 0.0, 85: 0.0, 84: 0.0, 95: 0.0, 96: 0.0, 64: 0.0, 73: 0.0, 56: 0.0, 74: 0.0, 100: 0.0, 58: 0.0, 102: 0.0, 71: 0.0, 124: 0.0, 57: 0.0, 86: 0.0, 91: 0.0, 79: 0.0, 83: 0.0, 67: 0.0, 60: 0.0, 62: 0.0, 93: 0.0, 88: 0.0, 69: 0.0, 89: 0.0, 8: 0.0, 59: 0.0, 63: 0.0, 48: 0.0}

At first glance, there are communities that stand out amongst the pack, which suggests this top community may have a stronger connection to aging genes and is a central mechanism to aging. I’ve posted the entrez ids of the genes within community 32 below.

572, 580, 672, 675, 975, 1859, 1874, 3667, 4092, 4193, 4624, 4683, 4869, 5154, 5290, 5426, 5602, 5824, 5889, 7157, 7295, 7297, 7516, 8444, 8650, 8660, 9870, 10210, 10248, 10519, 10591, 10933, 11200, 11329, 11335, 11516, 11596, 11658, 11920, 12021, 12144, 12189, 12190, 12476, 12511, 12561, 12578, 12879, 12916, 12991, 13393, 13404, 13447, 13555, 14025, 14312, 14734, 15081, 15260, 15270, 15407, 15434, 15951, 16147, 17246, 17248, 17279, 17285, 17286, 17535, 17984, 18503, 18505, 18559, 18566, 18612, 18973, 19206, 19360, 19361, 19362, 19363, 19364, 19378, 20482, 20983, 21376, 21745, 21749, 21750, 21752, 21907, 22059, 22061, 22062, 22249, 22592, 22927, 23012, 23468, 23558, 24102, 25913, 26277, 26909, 26972, 27107, 27223, 27354, 29274, 29867, 50717, 50883, 51147, 53325, 54386, 54610, 55114, 55602, 56046, 56196, 56317, 56338, 56397, 56710, 56816, 57062, 57434, 57915, 58517, 58521, 59001, 64427, 64704, 64858, 65263, 66593, 66599, 66889, 67157, 67500, 67525, 67788, 68047, 68098, 69181, 69188, 70024, 70238, 70432, 71310, 71960, 72469, 72486, 72775, 72836, 72931, 72973, 73173, 74241, 74335, 74377, 74469, 75013, 75826, 76795, 77782, 78284, 79837, 83743, 84062, 84309, 90441, 90459, 93643, 93696, 93759, 100929, 101185, 102774, 104346, 105670, 106585, 107815, 109095, 109910, 114642, 114875, 140709, 140917, 175962, 191578, 192197, 200081, 208898, 216527, 223989, 224860, 225182, 226419, 227325, 227624, 231201, 233826, 234069, 234776, 235180, 235559, 235610, 237211, 240087, 244329, 244698, 245000, 245638, 319583, 320214, 329581, 374920, 379888, 381107, 381802, 382985, 641373, 1489531, 3707654, 100035767, 100041687, 100504617

Now here’s the score data for the genes in community 32 that have score data. We can see it’s pretty sparse in comparison to the 229 total genes in the community. However, this is only 1758 genes spread out over 19299 total genes in biogrid, it’s likely to be sparse. Given it’s the top result, the other genes may deserve some examination, but it is pretty weak overall. However, it is also possible the Louvain split method isn’t splitting the network optimally, since in the previous research showed a much more closely connected network for the aging genes than the randomized controls. But at this point, this is the best that we can do. The fact may still be that aging is a diffuse mechanism.

11920: (1.0001211240310077, True), 12189: (0.7143633720930233, True), 12190: (0.3730295542635659, True), 12578: (0.9250886627906977, True), 13555: (0.2462422480620155, True), 15270: (0.8028478682170543, False), 15434: (0.002121124031007752, False), 17246: (0.5083028100775194, True), 17248: (0.05612112403100775, False), 17279: (0.08466618217054264, False), 17984: (0.022237887596899226, False), 18505: (0.08012112403100775, False), 22059: (0.3225436046511628, False), 67788: (0.001937984496124031, False), 93759: (1.0051477713178294, True)
